Air flow at 1 speed - extractor by EN 61591 281 m3/h |
Air flow at 2 speed - extractor by EN 61591 487 m3/h |
Air flow at 3 speed - extractor by EN 61591 639 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 639 m3/h |
Air Flow at Minimum Speed in Normal Use 281 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 332.1 m3/h |
Air Pressure at Best Efficiency Point P BEP 430 Pa |
Éves energia fogyasztás 45.7 kWh |
Éves energiafogyasztás 45.7 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 116 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 334,5 x 274,5mm |
Display color Red |
Distance from light cover to wall 43 cm |
Distance to electric hob 45 cm |
Distance to gas hob 65 cm |
Electric Power Input at Best Efficiency Point - W BEP 130.4 W |
Energy Efficiency Index - EEI hood 51.2 |
Fluid Dynamic Hatékonyság 30.4 |
Fluid Dynamic Hatékonyság A |
Grease Filtering Efficiency - GFE hood 75.2 % |
Zsírszűrési hatékonyság C |
Gross volume 0.2644 m³ |
Internal/external motor Internal |
Main lighting colour temperature [K] 3000 |
Világítás 30 lux/W |
Világítási hatékonysági osztály A |
Világítás A |
Maximum Possible Air Flow 639 m3/h |
Motor unit rated power 210 W |
Motor type/model SM650 |
Net depth 50 cm |
Net height max 103.5 cm |
Net height min 65.5 cm |
Nettó tömeg 15.4 kg |
Net width 89.8 cm |
Zajszint 48 dB |
Zajszint 63 dB |
Zajszint 67 dB |
Nominal Power of the Lighting System - W L 3.9 W |
Number of motor units 1 |
Number units of main lighting 2 |
Légkifújó átmérője 15 cm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.3 W |
Power cabel length 200 cm |
Power rating 213 W |
Tápfeszültség 220-240V |
Power unit of main lighting 1.5 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 67 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 48 dB |
Zajszint 67 dB |
Time Increase Factor - f 0.9 |
Type of main lighting LED - other |
