Air flow at 1 speed - extractor by EN 61591 153 m3/h |
Air flow at 2 speed - extractor by EN 61591 209 m3/h |
Air flow at 3 speed - extractor by EN 61591 403 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 403 m3/h |
Air Flow at Minimum Speed in Normal Use 152 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 206.7 m3/h |
Air Pressure at Best Efficiency Point P BEP 163 Pa |
Éves energiafogyasztás 66 kWh |
Éves energia fogyasztás 66 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 277 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 250x300x9 mm |
Display color No |
Distance from light cover to wall 3 cm |
Distance to electric hob 45 cm |
Distance to gas hob 65 cm |
Electric Power Input at Best Efficiency Point - W BEP 101.4 W |
Energy Efficiency Index - EEI hood 88.9 |
Fluid Dynamic Hatékonyság 9.2 |
Fluid Dynamic Hatékonyság E |
Grease Filtering Efficiency - GFE hood 71.2 % |
Zsírszűrési hatékonyság D |
Gross volume 0.1344 m³ |
Internal/external motor Internal |
Világítás 46.1 lux/W |
Világítási hatékonysági osztály A |
Világítás A |
Maximum Possible Air Flow 403 m3/h |
Motor unit rated power 115 W |
Motor type/model K-28 HE |
Net depth 50 cm |
Net height max 104 cm |
Net height min 76 cm |
Nettó tömeg 8 kg |
Net width 60 cm |
Zajszint 46 dB |
Zajszint 51 dB |
Zajszint 64 dB |
Nominal Power of the Lighting System - W L 6 W |
Number of motor units 1 |
Number units of main lighting 2 |
Légkifújó átmérője 15 cm |
Type of plug or cable Euro plug |
Power cabel length 170 cm |
Power rating 121 W |
Tápfeszültség 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 64 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 46 dB |
Zajszint 64 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED |
