| Air flow at 1 speed - extractor by EN 61591 96 m3/h |
Air flow at 2 speed - extractor by EN 61591 127 m3/h |
Air flow at 3 speed - extractor by EN 61591 171 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 171 m3/h |
Air Flow at Minimum Speed in Normal Use 96 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 99.8 m3/h |
| Air Pressure at Best Efficiency Point P BEP 182 Pa |
Éves energiafogyasztás 41.7 kWh |
Éves energia fogyasztás 41.7 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 61 lux |
Control panel on one side/two sides One side |
Dimensions of grease filter 300 x 390 mm |
| Display color No |
Distance from light cover to wall 3.5 cm |
Distance to electric hob 45 cm |
| Distance to gas hob 65 cm |
Electric Power Input at Best Efficiency Point - W BEP 62.2 W |
Energy Efficiency Index - EEI hood 80.5 |
| Fluid Dynamic Hatékonyság 8.1 |
Fluid Dynamic Hatékonyság E |
Grease Filtering Efficiency - GFE hood 67.5 % |
| Zsírszűrési hatékonyság D |
Gross volume 0.0292 m³ |
Internal/external motor Internal |
Világítás 14.5 lux/W |
Világítási hatékonysági osztály D |
Világítás D |
Maximum Possible Air Flow 171 m3/h |
Motor unit rated power 85 W |
Motor type/model K-20 025 02 HE |
Net depth 48.5 cm |
Net height max 8.5 cm |
Net height min 8.5 cm |
Nettó tömeg 3.9 kg |
Net width 50 cm |
Zajszint 53 dB |
Zajszint 58 dB |
Zajszint 63 dB |
Nominal Power of the Lighting System - W L 4.2 W |
Number of motor units 1 |
Number units of main lighting 1 |
Légkifújó átmérője 12 cm |
Type of plug or cable Euro plug |
Power cabel length 220 cm |
Power rating 89 W |
Tápfeszültség 230V |
Power unit of main lighting 4 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 63 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 53 dB |
Zajszint 63 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED |
LED világítás
