IN900BI
IN900BI
Specification
FEATURES
| Accessories - | Air flaps Yes | Delay Yes |
| High efficiency Yes | Maximum time of delay 10 ' | Panel - language version Pictograms |
| Protection class of electric shock I_Class | Low noise level No | Type of work Extraction/Recirculation |
Equipment
| Number of carbon filters 3 | Number of grease filters 3 | Number of layers in grease filter 5 |
| Number of speed 4 | PowerBooster Yes | Type of control Sensor |
| Type of grease filters Aluminium frame | Carbon filter type FWK 280 |
Technical data
| Frequency 50 | Air flow at 1 speed - extractor by EN 61591 275 m3/h | Air flow at 2 speed - extractor by EN 61591 356 m3/h | ||||||||||||||||||||||||||||||||||||
| Air flow at 3 speed - extractor by EN 61591 439 m3/h | Air flow at 4 speed - extractor by EN 61591 708 m3/h | Air Flow at Intensive or Boost Setting [If Available] 708 m3/h | ||||||||||||||||||||||||||||||||||||
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 439 m3/h | Air Flow at Minimum Speed in Normal Use 275 m3/h | Air Flow Rate at Best Efficiency Point - Q BEP 402.3 m3/h | ||||||||||||||||||||||||||||||||||||
| Air Pressure at Best Efficiency Point P BEP 381 Pa | Annual energy consumption 75.7 kWh | Annual energy consumption 75.7 kWh | ||||||||||||||||||||||||||||||||||||
| Average Illumination of the Lighting System on the Cooking Surface - E middle 595 lux | Control panel on one side/two sides One side | Dimensions of grease filter 250 x 300 mm | ||||||||||||||||||||||||||||||||||||
| Display color Red | Distance to electric hob 45 cm | Distance to gas hob 65 cm | ||||||||||||||||||||||||||||||||||||
| Electric Power Input at Best Efficiency Point - W BEP 155.3 W | Energy Efficiency Index - EEI hood 65.8 | Fluid Dynamic Efficiency - FDE hood 27.4 | ||||||||||||||||||||||||||||||||||||
| Fluid Dynamic Efficiency Class B | Grease Filtering Efficiency - GFE hood 69.9 % | Grease Filtering Efficiency Class D | Gross volume 0.3608 m³ | Intensive or Boost Setting Auto-Off time 5 ' | Internal/external motor Internal | Lighting Efficiency - LE hood 22.9 lux/W | Lighting Efficiency Class B | Lighting Efficiency Class B | Limitation of Exhaust Air - t limit 8 ' | Maximum Possible Air Flow 708 m3/h | Motor unit rated power 260 W | Motor type/model S-45 004 01 | Net depth 59.5 cm | Net height max 105.2 cm | Net height min 85.2 cm | Net weight 27.1 kg | Net width 90 cm | Noise level at 1 speed - extractor by EN 60704-2-13 52 dB | Noise level at 2 speed - extractor by EN 60704-2-13 57 dB | Noise level at 3 speed - extractor by EN 60704-2-13 62 dB | Noise level at 4 speed - extractor by EN 60704-2-13 68 dB | Nominal Power of the Lighting System - W L 26 W | Number of motor units 1 | Number units of main lighting 2 | Air exhaust diameter 15 cm | Type of plug or cable Euro plug | Power Consumption in Standby Mode - Ps 0.25 W | Power cabel length 200 cm | Power rating 286 W | Power Supply Voltage 230V | Power unit of main lighting 13 W | Noise level on TURBO mode 68 dB | Sound Power Emission at Intensive or Boost Setting [if available] 68 dB | Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 62 dB | Sound Power Emission at Minimum Speed Available in Normal Use 52 dB | Noise level 62 dB | Time Increase Factor - f 1 | Type of main lighting LED |
